GEKO

MINI clamp W1 16-18mm

SKU: G17400 Barcode: 5901477181191.0
(0)
€2,50 inc. VAT
In stock
Usually ships within 24 hours

Ready to work out of the box!

All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!

Got questions?

Feel free to get in touch

Ask an expert!

Chat Email +31 614585749

Mini GBS hose clamps made of galvanized steel W1 with a hinged closure intended for making connections on hoses and pipes of small diameter exposed to high loads. The clamps made of steel tape have bent edges, which prevent hose damage even under very strong clamping. Mini GBS type hose clamps are used for loaded connections, hoses with an externally ribbed surface, hoses with thick and strong walls, as well as suction hoses with an internal metal spiral or made of plastic. These 16-18mm clamps deliver reliable performance in demanding applications where standard fastening solutions fall short. The galvanized steel construction provides excellent corrosion resistance, ensuring durability in both indoor and outdoor environments. The hinged design allows for quick installation and adjustment without requiring complete disassembly of connected components. The rolled edge profile distributes clamping force evenly across the hose surface, minimizing stress concentration and extending hose lifespan. Ideal for automotive, industrial, and hydraulic systems where secure, vibration-resistant connections are critical.

Product characteristics:

  • made of galvanized steel – W1
  • intended for connecting hoses and pipes operating under high load
  • bent edges prevent hose damage even under very strong clamping
  • operated using a hexagonal wrench
  • for use in non-corrosive environments

Technical data:

Product code Ø - diameter Material A - tape width [mm] B - tape thickness [mm] Quantity in package
G17390 6-8mm W1 9mm 0.4mm 10 pcs.
G17391 7-9mm W1 9mm 0.4mm 10 pcs.
G17392 8-10mm W1 9mm 0.4mm 10 pcs.
G17393 9-11mm W1 9mm 0.4mm 10 pcs.
G17394 10-12mm W1 9mm 0.4mm 10 pcs.
G17395 11-13mm W1 9mm 0.4mm 10 pcs.
G17396 12-14mm W1 9mm 0.4mm 10 pcs.
G17397 13-15mm W1 9mm 0.4mm 10 pcs.
G17398 14-16mm W1 9mm 0.4mm 10 pcs.
G17399 15-17mm W1 9mm 0.4mm 10 pcs.
G17340 16-18mm W1 9mm 0.4mm 10 pcs.
